Catalac 8M / 9M Mast Lowering Instructions

The Catalac 8M and the 9M have a tabernacle designed to raise and lower the mast. Chainplates are mounted at the pivot point and the procedure is both simple and convenient. Read how I dropped my mast, replaced everything at the top and rewired it, all in an afternoon. (click here) . Note the mast support wires in the drawing below. These are necessary. Remove all Sails, The Boom and the Mainsheet ( rope & Blocks ). Slot your 50mm Mast Lowering Boom into the base of the mast. Shackle the forward end of your main Halyard to one of the eye at Front of Pole, Then  lifting the pole so that it is horizontal & secure, tie the other end of the halyard to a cleat on the lower part of the mast. For added security you can also connect the jib halyard in the same way. Shackle the end of […]

Memories of my Catalac 27

by Hak Kauffman (note: Hak Kauffman bought his Catalac 27 in 1977 and sailed it for 20 years. In those early catamaran days, he was one of the brave pioneers who took a chance on these new styled boats. Hak sold the boat when his age caught up to him, but has vivid recollections of his, which he was kind enough to share with us – Rick) Catalac 27 In my search for a new bigger boat, I decided to include multihulls. After a trip to Symons Sailing in Amityville, Long Island, NY, I thought the 8 meter Catalac would be the answer. About a month later, Bill told me he now had a new one at his place. So, my wife and three sons drove up to inspect and decide. We all liked what we saw, but I requested a short “get acquainted” sail, after we had lunch. We found […]

Catalac 8M Information

Pocket Cruiser with impeccable safety record The Catalac 8M is a pocket cruising catamaran which has a solid reputation for quality, strength and durability. Many of the boats found in North America today, were sailed there from Great Britain. The Catalac 8M, although classified as a pocket cruiser was designed with blue water sailing in mind. Twin diesel models can easily motor almost 1000 kilometers without refueling. The 70 amps of charging and 70 gallons of stock water tanks in the Catalac 8M and 9M make even these smaller boats terrific coastal cruisers. Constructed with solid fiberglass hulls, these are quality boats which were built like battleships. Chuck Kanter calls them one of the catamaran brands that live on through the decades. The Catalac 8M is masthead rigged with a relatively short, but thick mast. As with all boats in the Catalac production lineup, this contributes to a stable boat […]

Bravo II: A British Built Bay Cruiser

Hak Kauffman, and bis wife Adele, bad been sailing for eight years when, in 1977, the middle-aged couple found their perfect combination of speed versus accomodation in their 27-foot Calalac cruising catamaran. They were anchored in Spa Creek this week during their annual summer cruise, and the Cherry Hill, New Jersey sailors took time to chat about their spacious little multihull, and their sailing. S/V Bravo II stays on the Middle River. east of Baltimore. The Kauffmans bought the English boat in Amityville, L.I. and he sailed it south on the maiden voyage. They have cruised to all parts of Chesepeake Bay, just all over, including the York River, up and down the Potomac with stops at St. Mary’s City, and down to the Rapahannock. Before the Catalac, they had a good sized Bristol — and still maintain their affiliation with the Chesapeake/ Bristol Club, which will he celebrate its […]

Catalac 8M Diesel Engine Removal, Rebuild & Reinstall

One of my very few peeves about the Catalac 8M has to do with the inboard diesel engine placement. Apparently boat balance dictated the engine position in the boat. In actuality,  the Yanmar 1GM10s were placed so far forward in the engine compartments that the front of the engine is just 3 inches (75cm) from the rear bulkhead. The engines are almost literally mid engine mounted. Unfortunately, the Yanmar water pump, external oil lines, oil filter, thermostat ..etc..are all located on the front of the engine and are not easily accessible for normal maintenance. (Or I’m just too old to bend into a pretzel) For years, I’ve been forced to figure out long, time consuming ways to perform normal maintenance on my diesels. It’s been frustrating to say the least. Finally, an overly warm engine and leaking oil lines in my starboard engine, were the catalyst for me to pull […]

Catalac 8M upgrade Rudders and install Skegs

by Didier Grietencontact Didier Grieten When I bought my 8M, it was equipped with the older style lifting steel blade rudders.The rudder blades however were in very bad condition, with considerable corrosion and rust. Also, the wood support structure had to be replaced as it was rotting away and looking at the rudder blades showed they required some TLC as well. In some areas thickness was reduced to 50% and rust still working to get it even thinner… This meant some serious work on the rudders was required… Here’s what it was supposed to look like: I had three options, the first being replace the wood, remove the heavily corroded areas and weld in new material or just entirely replace the steel blades with new ones, get them galvanized and throw on a few coatings of paint… The second one was to replace the whole rudder setup with the newer […]

Struck by Lightning while under way

I should be dead I imagine that if you live in the lightning capital of the world, itS unavoidable. Sooner or later the boat will be hit by lightning. However, usually it occurs when no one is on board. I should be so lucky. In our case, we had a front row seat as we were hit by lightning on what began as a perfect sailing afternoon. Southwinds, a sailing magazine, recently featured an article on lightning strikes and boats in their June 2009 issue, and mentioned my experience in their story.  Click here to read my Lightning hit story in print. (It’s on page 44.) Afternoon storms are as regular as clockwork in summer months in central Florida. For that reason I usually leave the dock just as offshore winds are building in mid morning and try and be back in our slip before the storms hit. One Saturday, household chores […]

Sailing through a hurricane

Caught in a hurricane When I completed the sales transaction and took ownership of my Catalac 8M, I was hundreds of miles from home. I couldn’t wait to bring her home and put out a call to friends and family for crew. I accepted my brother’s gracious offer to give me a hand. He has a solid power boat backround these days and when we were kids we spend every minute we could in boats on Long Island Sound and the north Atlantic, and we both survived it. At the time, I really thought he’d enjoy the trip, as this was Florida. Tropical breezes and all that. What’s not to like? In retrospect, my brother didn’t fully appreciated the max speed under power of 6.5 knots we achieved with Catalpa. I still picture him shoving the throttles to their stops, with a quizzical look on his face when she didn’t go […]

Catalac 8M Performance Page

This page is fairly technical … but in 2005 the Catalac 8M was my new boat and calculating performance characteristics satisfied my curiousity.  Essentially this page displays crucial data which is used to calculated max speed and stability for the Catalac 8M / 9M (same hulls). The data can be used in the context of hull design or racing handicaps. There’s no way a Catalac 8M (or most cruising catamarans for that matter) can be mistaken as a racer. The link to my hull design formula page can be found here.Catamaran Hull design page Catalac 8M / 9M Specifications

Catalac 8M/9M Rigging Tune

Sailboat Rig tuning is an art rather than a science and varies from boat to boat and from low winds to high winds. Remember that the rigging on a monohull unloads as the boat heels and spills wind out of it’s sails. When you look at Catamaran rig tuning, we have to keep in mind that our rigs never unload. We have stiffer masts because of this and larger diameter wire stays. As with all sail boats, the rigging not only holds up your mast, but also has an effect on sail shape, and therefore affects performance.Racing boats have several rig tension setups depending upon wind speed the day of the race. For a cruising boat, this is impractical, and it makes more sense to aim for one rigging setup that pretty much fits all the conditions. At the same time addressing two of my particular challenges that need help. […]
